Original price was: 555,00 €.499,00 €Current price is: 499,00 €.
| Channels | 5 – 3 |
| Amp class | D |
| POWER SUPPLY | |
| Nominal power supply voltage (fuse) | 11 ÷ 15 VDC (2 x 30 A) |
| Operating power supply voltage | 9 ÷ 18 VDC |
| Idling current | 1.90 A |
| Standby current draw | 4 uA |
| Consumption, MIN load impedance (Max Musical Power) | 48 A |
| Remote IN | 4 ÷ 17 VDC (1 mA) |
| ART – Automatic Remote Turn on/off from SPK-IN (BTL radio only) | 1.5 VDC |
| Efficiency | 83% |
| AMPLIFIER STAGE | |
| Distortion – THD @ 100 Hz, 70% Rated Power | 0,01 % (F/R Ch) – 0,06 % (SUB Ch) |
| Damping factor @ 1 kHz, 1W | 160 (F/R Ch) – 180 (SUB Ch) |
| Bandwidth @ -3 dB | 10Hz ÷ 47kHz (F/R Ch) – 10Hz ÷ 500Hz (SUB Ch) |
| S/N ratio (A-weighted @ 1 V Input) | 101 dBA (F/R Ch) – 116 dBA (SUB Ch) |
| Minimum load impedance | |
| @ 5 Ch: | 2 Ω |
| @ 3 Ch: | 4 Ω + 4 Ω + 2 Ω |
| Adjustable Crossovers | yes |
| Output power (RMS) @ 1% THD: | |
| 5Ch @ 4Ω | 80 W x 4 + 330 W x 1 |
| 5Ch @ 2Ω | 130 W x 4 + 510 W x 1 |
| 3Ch @ 2Ω / 4Ω | 260 W x 2 + 510 W x 1 |
| 2Ch @ 4Ω | 260 W x 2 + 320 W x 1 |
| Total Power | 1030 W |
| Inputs | Pre-In / Speaker-In |
| Pre Out | Full Range (Front) |
| Pre-In sensitivity | 0.32 ÷ 8 VRMS |
| Speaker-In sensitivity | 1.6 ÷ 40 VRMS |
| Front Ch Hi-Pass | Full / 50-5000Hz 12dB/Oct. |
| Rear Ch Lo-Pass | Full / 50-5000Hz 12dB/Oct. |
| Sub Ch Lo-Pass | 50 ÷ 500 Hz @ 24 dB/Oct. |
| Bass Boost 50Hz | 0 ÷ 9 dB |
| Subsonic Hi-Pass | 25 Hz @ 24 dB/Oct. |
| Sub Remote Volume Control | -20 ÷ 6 dB (Active on Sub Ch) |
| Weight | 3,54 kg |
|---|---|
| Dimensions | 40,5 × 40,5 × 9,5 cm |
| Αντίσταση | |
| Ενσωματωμένο SDSP | |
| Ισχύς | |
| Κανάλια |
